SMART Transmitter: 4-20mA + HART protocol Span limit : from 10 to 300.000 mmWC Rangeability : 100:1 Accuracy: 0.165% (0.1% as an option) Power supply 10.5 to 45VDC Process wetted parts material avec le fluide en 316L st. st., Hastelloy, Monel, Tantalum, … Process connection by flange Burnout according NAMUR NE43 recommandations Long term stability: +/- 0.1% of maximum span / 10years Options: » Local analog or digital indicator » Intrinsically safe version » Explosion proof version » FM, CSA and IECEx certification » Stainless Steel electronic housing The ProcessX level transmitter accurately measures liquid level and transmits a proportional 4 to 20 mA signal.The transmitter utilizes a unique micromachined capacitance silicon sensor with state-of-the-art microprocessor technol-ogy to provide exceptional performance and functionality. FEATURES 1. HigH accuracy 0.165% accuracy for all calibrated spans is a standard feature. The micro-capacitance silicon sensor assures this accuracy for all elevated or suppressed calibration ranges without additional adjustment.0.1% accuracy is available as option. 2. MiniMuM inventory and design Electronics unit, local indicators and electronics hous-ing are interchageable among all ProcessX transmit-ters. 3. MiniMuM environMental inFluence The “Advanced Floating Cell” design which protects the pressure sensor against changes in temperature, static pressure, and overpressure substantially reduces total measurement error in actual field applications.
Технические характеристики
CharacteristicsTechnologycapacitiveMediumfor liquidsInterface4-20 mA, HART, Modbus, PROFIBUS, NAMURApplicationsfor storage tanksOther characteristicsstainless steel, flange-mount, explosion-proof, intrinsically safe, smart, IP67, IP66Process pressure
Min.: 0 bar (0 psi)
Max.: 100 bar (1,450.38 psi)
Process temperature
Min.: -40 °C (-40 °F)
Max.: 85 °C (185 °F)
