HBS-3000 digital display Brinell hardness tester Main features : Innovative design, solid construciton ,high test efficiency , Weight adding system ,LCD display test process, On-board measurement, can be converted Rockwell, Vickers hardness and tensile strength, then print hardness test results, Large LCD liquid crystal display, menu intellisense, easy to operate, Video system and CCD image processing system optional, Precision conforms to the Standards of GB/T 231.2, ISO 6506-2 and ASTM E10. Application: It’s suitable to determine the Brinell hardness of ferrous metals, nonferrous metals and bearing alloy materials, Wide range of applications, especially for parallel plane precision measurement. Specifications: Measuring range 8-650HBW Test force 1838.8,2451.8,4903.5,7355.3,9807,29421N (187.5,250,500,750,1000,3000kfg) Max. height of test piece 235mm Depth of throat 120mm Optical magnification 20x Min test unit 1μm Power AC220V 50/60HZ Dimension 705*215*880mm
Технические характеристики
CharacteristicsTypeBrinellMountingbenchtopOther characteristicsLCD digital displayLoad
Max.: 3,000 kgf
Min.: 187.5 kgf
Weight
200 kg (440.9 lb)
