Sick WL9G-3P2432
Datasheet:
- Article: 1049083
- Device type: Photoelectric sensors
- Sensor/detection principle: Reflective sensor, Autocollimation
- Dimensions (W x H x D): 12.2 mm x 52.2 mm x 23.6 mm
- Housing shape (light output): Rectangular
- Hole pattern: M3
- Operating distance, max.: 0 m … 5 m
- Sensing distance: 0 m … 3 m
- Type of radiation: Visible red light
- RADIATION SOURCE: PinPoint LED
- Light spot size (distance): Ш 45 mm (1.5 m)
- Wavelength: 650 nm
- Settings: Settings button
- AutoAdapt: ?
- Special applications: Detection of transparent objects
- Supply voltage: 10 V DC … 30 V DC li>
- Residual ripple: ss
- Current consumption: 20 mA
- Switching output: PNP
- Function output signal: Complementary
- Switching type: LIGHT/DARK
- Output current Imax: ? 100 mA
- Rating:
- Switching frequency: 1,000 Hz
- Connection type: M12 connector, 4-pin
- Protection circuits: A , B , C ,
- Protection class: III
- Weight: 13 g
- Polarizing filter: ?
- Case material: Plastic, VISTAL®
- Material, optics: Plastic, PMMA
- Protection type: IP66, IP67, IP69K,
- Special version: Detection of transparent objects
- Temperature range during operation : –40 °C … +60 °C
- Storage temperature range: –40 °C … +75 °C
- UL File No: NRKH.E181493
- MTTFD: 1.232 years
- DCavg: 0%
- Series:W9
- Sensing distance:0 … 3 m
- Output type:PNP
- Type of radiation: visible red light
