WEU26/3-203A00S01
Datasheet:
- Item number: 1089127
- Scanning range: 70 m
- Beam path length: 15 m … 70 m
- Number of beams: 1
- Detection ability: 30 mm
- Evaluation: ? 22 ms
- Heated front glass: ?
- Synchronization: Optical synchronization
- Type: Type 4 (IEC 61496-1)
- Reliability class: SIL3 (IEC 61508), SILCL3 (EN 62061)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- B10d value: 1 x 106 actuation cycles , 2 x 105 operating cycles
- PFHd (average probability of dangerous failure per hour): 4.0 x 10-9 (EN ISO 13849)
- TM (targeted operating time): 20 years (EN ISO 13849)
- Safe state in case of error: At least one OSSD output is in in AUS state (OFF).
- Connection type: M12 connector, 8-pin.
- Indication elements: LEDs
- Protection class: I (EN 50178 )
- Supply voltage UV: 24 V DC (19.2 V DC … 28.8 V DC)
- Power consumption: ? 8 W
- On delay: ? 10 s
- Discrete outputs: Relay
- Housing type: Rectangular
- Dimensions (W x H x D ): 50 mm x 156 mm x 116 mm
- Case material: Die-cast aluminum
- Front glass material: Polycarbonate, scratch-resistant
- Weight: ? 1 kg
- Protection type: IP67 (EN 60529)
- Operating temperature range: –25 °C … +55 °C
- Storage temperature: –25 ° C … +70 °C
- Air humidity: 15% … 95%, non-condensing
- Vibration resistance: 5 g, 10 Hz … 55 Hz (IEC 60068-2-6)
- Shock resistance: 10 g, 16 ms (IEC 60068-2-29)
- Integration via Flexi Soft safety controller: CANopen
- : DeviceNet
- : EtherCAT®
- : EtherNet/IP
- : Modbus TCP
- : PROFIBUS DP
- : PROFINET
- Consumption category: AC-15/DC-13 (EN 60947-5-1)
- Switching voltage: 10 V DC … 30 V DC
- : 10 V AC … 230 V AC
- Permissible current load of the output switching device: 0.02 A … 2 A
- Contact material: Gold-plated silver alloy
- Electrical component life (relay contacts): ? 1 x 105 operating cycles
- Mechanical service life components (relay contacts): ? 1 x 107 operation cycles
- Category:Single beam safety light curtains
- Series:WSU/WEU26-3
