Sick VT12T-2P112
Datasheet:
- Article No.: 6026211
- Sensor/detection principle: Reflective sensor, energy
- Dimensions (W x H x D): 12 mm x 12 mm x 54.5 mm
- Housing shape (light output): Cylindrical
- Housing length: 54.5 mm
- Thread diameter (housing): M12 circular plug connector x 1
- Operating distance, max.: 0 mm … 115 mm
- Sensing distance: 2 mm … 100 mm
- Focus: Approx. 11.4°
- Type of radiation: Infrared light
- RADIATION SOURCE: LED
- Light spot size (distance): Ш 20 mm (100 mm) li>
- Emission angle: Approx. 11.4°
- Wavelength: 880 nm
- Settings: Setting button (Sensing distance), Optionally via control input C (Sensing distance),
- Supply voltage: 10 V DC … 30 V DC
- Residual ripple: ± 10%
- Current consumption: 20 mA
- Switching output: PNP
- Switching type: LIGHT/DARK
- Selectable switching type: Selectable via control input C
- Output current Imax. : ? 100 mA
- Rating: ? 1.25 ms
- Switching frequency: 400 Hz
- Connection type: Cable, 4-wire, 2 m
- Cable material: PVC
- Wire cross-section: 0.14 mmІ
- Wire diameter: Ш 3.75 mm
- Protection circuits: A , B , C , D ,
- Protection class: III
- Weight: 54 g
- Case material: Metal, Nickel-plated brass / PA
- Material, optics: Plastic, PMMA
- Protection type: IP67
- Operating temperature range: –25 °C … +70 °C
- Range Storage temperatures: –25 °C … +70 °C
- UL File No.: E175606
- Series: V12-2
- Sensing distance:2 … 100 mm
- Output type:PNP
- Type of radiation: infrared light
