Больной S30A-7111CL

**Part Number:** 1052595
**Supply voltage:** 16.8 V DC, 24 V DC, 28.8 V DC
**Hazardous area protection (vertical):** +
**Number of monitoring cases:** 4
**Laser class:** 1 (21 CFR 1040.10 and 1040.11, DIN EN 60825:2001)
**Interfaces for configuration and diagnostics using CDS:** TCP port 9000 and UDP port 30718, RS-232
**Distance measuring range:** 49 m
**Weight:** 3.3 kg
**Type of field set:** Dual field sets
**PFHd:** 8.0 1E-08 (EN ISO 13849)
**Safe SICK device communication via EFI/SDL:** —
**Functions that are not supported:** Multicast communication
, Supervisor AR
, MAC-pause mechanism in full duplex
, Back-pressure in half duplex
, Static learning
, Broadcast Storm Control
**Topology support:** SNMP, MIB-2, LLDP nach IEEE 802.1AB
, MRP client support
**Port properties:** Auto-negotiation
, Auto-crossover (MDIX)
, Auto-polarity
, 100Base-FX
**Integrated configuration memory:** +
**Type:** Type 3 (IEC 61496)
**Enclosure rating:** IP 65 (EN 60529)
**Electrical connection:** Optical fiber conductor (2 female connectors for SCRJ push-pull plug), system plug with or without connecting cable
**Number of multiple samplings:** Configurable 2 … 16
**Configuration and diagnostics interface:** RS-232
**Static protective field switching:** +
**Performance level:** PL d (EN ISO 13849)
**Maximum warning field range:** 49 m
**Diagnostics:** Application-related manufacturer-specific channel diagnostics and channel diagnostics for the PROFIsafe profile, individually switchable
, Report system errors
, Maintenance alerts for POF interfaces for signal quality
, Cable diagnostics
, Neighborhood alerts
, Support for port statistics
, I&M support from I&M0 to I&M4
**Safety integrity level:** SIL2 (IEC 61508), SILCL2 (EN 62061)
**Device properties:** GSDML according to GSDML specification V2.25, PROFINET IO device with 2-port real-time switch according to PROFINET specification V2.2, PROFIsafe profile with 6-octet input and 6-octet output according to IEC 61784-3-3 V2.4, Cycle time 4, 8, 16, 32 ms, etc.
**Hazardous area protection (horizontal):** +
**Access protection (vertical):** +
**TM (mission time):** 20 a (EN ISO 13849)
**Number of field sets:** 4
**Response time:** 60 ms
**Conformance:** Conformance Class B
**Dimensions (W x H x D):** 155 mm x 185 mm x 160 mm
**Incremental encoder inputs:** —
**Category:** Category 3 (EN ISO 13849)
**Switch properties:** Filtering Data Base according to IEEE 802.1D
, 6 prioritization levels for IEEE 802.1Q — Network prioritization
, 64 KB SRAM memory for caching telegrams, managed in 768-byte segments
, Resource prioritization for network control and RTC2/3 frames
, Telegram extension based on «Cut-through»
, Port status (Disabled, Blocking, Forwarding)
, Support for non-real-time and real-time data transfer
**Number of simultaneously monitored protective fields:** 2
**Protective field range:** 7 m
**Measured data output:** +
**Expanded measured data output (CMS):** —
**Protection class:** III (VDE 0106, EN 60950)
**Scan angle:** 190 °
**Ambient operating temperature:** -10 °C … +50 °C
**External device monitoring (EDM):** —
**Resolution:** 30 mm, 40 mm, 50 mm, 70 mm, 150 mm, configurable

---
