Specification:
| Part Number | 1041551 |
| Vibration resistance: | EN 60068-2-6 (1995) |
| Data transmission rate (Serial (RS-232, RS-422/485)): | 2,400 Baud … 115 Baud, AUX: 57.6 kBaud |
| No. of multiple readings: | 1 … 99 |
| Housing color: | Light blue (RAL 5012) |
| MTBF: | 40,000 h |
| Dimensions: | 80 mm x 66 mm x 38 mm |
| Optical indicators: | 6 LEDs (Ready, Result, laser, Data, CAN, LNK TX) |
| Light source: | Visible red light (655 nm) |
| Laser class: | 2 (EN 60825-1 (A2:2001-03)) |
| Switching inputs: | 3 (“Sensor 1”, 2 inputs via optional parameter storage CMC600 in CDB620/CDM420) |
| Shock resistance: | EN 60068-2-27 (1993) |
| Connection type: | Ethernet |
| Scanner design: | Line scanner |
| Function (Ethernet): | Host, AUX |
| Electromagnetic compatibility (EMC): | EN 61000-6-3 (2001-10) / EN 61000-6-2:2005 |
| Reading pulse: | Auto pulse, CAN, Non-powered, Switching inputs, Serial interface |
| Permissible relative humidity: | 90 %, non-condensing |
| Housing: | Die-cast aluminum |
| Weight: | 230 g, without connecting cable |
| CAN bus: | + |
| Configuration software: | SOPAS ET |
| Code resolution: | 0.2 mm … 1 mm |
| Operating voltage: | 10 V DC … 30 V DC |
| Scanning frequency: | 400 Hz … 1,200 Hz |
| Bar code types: | Interleaved 2 of 5, All current code types, Codabar, Code 128, Code 39, Code 93, GS1 DataBar, GS1-128 / EAN 128, MSI/Plessey, Pharmacode, Telepen, UPC / GTIN / EAN |
| No. of codes per scan: | 1 … 20 (Standard decoder), 1 … 6 (SMART620) |
| Bar code print contrast (PCS): | ≥ 60 % |
| Protocol (Ethernet): | TCP/IP, EtherNet/IP, PROFINET, PROFINET Dual Port (optional via external connection module CDF600-2), EtherCAT (optional via external connection module CDF600) |
| PROFIBUS DP: | + |
| Remark (PROFIBUS DP): | Optional via external connection module (CDF600-2) |
| Function (CAN bus): | SICK CAN sensor network (Master/Slave, Multiplexer/Server) |
| Remark (DeviceNet): | Optional via external connection module (CDM + CMF) |
| Field of view: | ≤ 50 ° |
| Electrical connection: | 2 x M12 cylindrical connectors (12-pin male connector, 4-pin female connector) on swivel connector |
| Print ratio: | 2:1 … 3:1 |
| Focus: | Fixed focus |
| Reading distance: | 60 mm … 365 mm |
| Reading field: | Side (105 °) |
| Protocol (CAN bus): | CANopen, CSN (SICK CAN Sensor Network) |
| Ethernet: | + |
| Data transmission rate (Ethernet): | 10/100 Mbit |
| Front screen: | Glass |
| Enclosure rating: | IP 65 (DIN 40 050) |
| Protection class: | III (VDE 0106/IEC 1010-1) |
| Version: | Mid Range |
| Switching outputs: | 2 (via CMC600 in CDB620/CDM420) |
| DeviceNet: | + |
| Acoustic indicators: | Beeper/buzzer (can be switched off, can be allocated as a result indication function) |
| Ambient operating temperature: | 0 °C … +40 °C |
| Function (Serial (RS-232, RS-422/485)): | Host, AUX |
| Serial (RS-232, RS-422/485): | + |
| Power consumption: | 4.5 W |
| Remark (Serial (RS-232, RS-422/485)): | AUX (only RS-232) |
| No. of codes per reading interval: | 1 … 50 (auto-discriminating) |
| Ambient light safety: | 2,000 lx, on bar code |
| Storage temperature: | -20 °C … +70 °C |
| Data transmission rate (CAN bus): | 20 kbit/s … 1 Mbit/s |
| No. of characters per reading interval: | 1,500, 500 (for multiplexer function in CAN operation) |
