Air Knives deliver a flat sheet of amplified air designed to: Efficiently blow off water and debris from wide surfaces Provide high-speed drying or cooling Air Knives are air amplifiers, using a small amount of filtered compressed air to deliver a powerful, high velocity, laminar sheet of air over wide areas such as moving webs, film, sheets, strips, auto bodies, and other large assemblies and objects. Vortec’s patented design produces increased thrust and velocity, reduced noise, and excellent uniformity. BENEFITS More uniform blow off of large surfaces than nozzles or jets Dries surfaces quickly and thoroughly Costs significantly less than fans or blowers Inherently safe, with no guards or rotating equipment Reduced compressed air usage, versus open nozzles Easily controlled output Quiet – meets OSHA requirements No electrical connections at the target site Easily mounted and moved Give a cleaner surface for painting or coating FEATURES 25 times air amplification over compressed air input High performance, patented design gives high thrust Interchangeable shims enable air flow to be adjusted for the specific application Air Knives available in lengths of 6, 12, 18 and 24 inches (152, 305, 457, 610 mm) Single compressed air inlet up to 12 inch (305 mm) length, dual inlet on longer models Instant on/off No moving parts, no maintenance Quiet – meets OSHA noise specifications
Технические характеристики
CharacteristicsApplicationsfor blowoff operations, cooling, for drying operations, for industrial applications, for the automotive industry, industrialProduct applicationsfor the food and beverage industryMaterialaluminumPressure
Min.: 2.06 bar (29.88 psi)
Max.: 6.9 bar (100.08 psi)
Air consumption
Min.: 23 ft³/min (0.65 m³/min)
Max.: 64 ft³/min (1.81 m³/min)
