Product Information
This miniature angle beam block is also known as a Rompas block or simply Angle Beam, and it is the ASTM and U.S. Air Force substitute for the DSC block for distance, beam index, refracted angle and sensitivity calibration. Contains a 1.0 radius opposite a 2.0 radius, and a 5/64 diameter x .750 deep flat-bottom hole.
In accordance with ASTM E164 and U.S. Bureau of Public Roads, Type B specifications.
- Dimensions: 1.000 thick.
- Also available in .500 thickness.
- Optional Hardwood Case available
Metric Versions available.
Looking for a Block made from an exotic alloy? Youve come to the right place! If you dont see what you need, please contact us!
We can offer many Steels (Carbon and Alloy), Stainless Steels, Nickel Alloys, Titanium Alloys, Aluminum Alloys, Copper Alloys, Cast Irons, Zirconium and others!
