Description
Description:
The BioLogic LP low-pressure chromatography system is used for biomolecule purification. Its compact design minimizes the workspace required in the coldroom or on the laboratory bench. The system includes both 254 and 280 nm filters for nucleic acid and protein detection, and a conductivity cell to monitor gradient progress.
LP Data View software captures data, multitasks, and prints data from any computer that runs on Windows 10 operating system. The system stores up to 50 methods, each method can include up to 50 pump steps and 50 fraction collection steps.
Features: Flow range: 0.1–40 ml/min Maximim counterpressure: 30 psi (2 bar) Gradient formation: Solenoid-activated proportioning valve
Mixer volume: 750 µl UV: Single channel, 280/254 nm with auto zero
Detection range: 0.001–2 AUFS Conductivity: Detection range: 0.5–500 mS/cm FS Temperature range: 4–40°C Sample Loading: Manual loop fill
Automatic loading through SV-5 buffer select valve Technical Specifications: BioLogic LP System Flow rate limit: 20 ml/min per channel, dual-channel peristaltic pump Pressure limit: 30 psi (0.2 MPa) UV Detection: 254 and 280 nm filters, 2 mm flow cell Conductivity: Standard Solvent Compatibility: All commonly used chromatographic solvents Operating tempurature: 4–40°C Dimensions (W x D x H): 24 x 33 x 25 cm
(9.5 x 13 x 9.8″) Weight: 19 kg (42 lb)
