Product Description Fast and Cool High g -Force for Fast and Optimal Pelleting Maintenance-free rotor spins up to 14,000 rpm (21,920 x g) Ideal for pelleting of DNA, RNA and Proteins, Cell Virus Isolation Maintains 4 C at maximum speed to protect precious samples Stand-by cooling Easy-to-use control knobs and easy-to-read display Comes complete with a 24-place aerosol-tight, autoclavable fixed-angle rotor Quiet operation <, 58 dB Interchangeable Rotors for Application Flexibility All rotors come standard with aerosol-tight lids minimizing contamination from broken or leaking tubes All rotors are autoclavable at 121C Technical Specifications Ventilation Clearances Required: 7.6 cm (3.0 in) Sides and Rear Humidity Restrictions: <, 80% (noncondensing) Ambient Temperature Range: 4 to 35C ambient Speed Range: 500 to 14,000 rpm Set Time: to 30 min, continuous run (8), or pulse (short run) Set Temperature: -10 to +40C in 2C increments Noise Level 1 Meter in Front of Centrifuge: 58 dBA Maximum Heat Dissipation into Room under Steady-State Conditions: 0.63 kW (2,150 Btu/hr) Approximate Deceleration Time: 19 seconds from max speed Approximate Acceleration Time: 18 seconds to max speed Weight 96 lbs Dimensions 23 x 15 x 12 Power 120V, 7amp
Технические характеристики
Technical Specifications
| Model | Beckman Allegra 6R | Beckman Allegra 6 | Beckman Allegra 6KR |
| Refrigeration | Yes, CFC-Free | No | Yes |
| Maximum Speed (rpm) | 6,100 (Fixed-angle) 3,750 (Swinging-bucket) | 6,100 (Fixed-angle) 3,750 (Swinging-bucket) | 4,730 rpm |
| Maximum g-Force (x g) | 5,710 (Fixed-angle) 3,210 (Swinging-bucket) | 5,710 (Fixed-angle) 3,210 (Swinging-bucket) | 4,550 |
| Maximum Capacity (mL) | 4 x 750 | 4 x 750 | |
| Run Time | Timed (0-30 min), Hold | Timed (0-30 min), Hold | 30 min timer, hold |
| Drive | Direct, Brush Type | Direct, Brush Type | Direct drive, Brushes Type |
| Noise at Max Speed | 65 dBa | 65 dBa | <, 60 dBA |
| Operating Temperature (ºC) | -5 to +25 | Ambient | — |
| Set Temperature Range (ºC) | -10 to +40 | N/A | -5° C to 25° C |
| Dimensions (cm, H x W x D), Lid Closed | 39.4 x 76 x 66 | 40.6 x 54.6 x 66 | — |
| Dimensions (in, H x W x D), Lid Closed | 15.5 x 30 x 26 | 16 x 21.5 x 26 | 67.3 x 54.6 x 66 |
| Weight without Rotor | 75.8 kg (167 lbs) | 51.7 kg (114 lbs) | 90.3 kg (200 lbs) |
