USB 3.0, 5.3 Megapixel, Color
| Sensor: onsemi PYTHON5000 | |
| Mono/Color: Color | Sensor type: 1″ CMOS |
| Shutter type: Global shutter | |
| Resolution: 2592 x 2048 px | |
| Pixel size: 4.8 x 4.8 µm | |
| Exposure time: 0.02 … 1000 ms | |
| Dark noise: 11.77 e- | |
| Saturation capacity: 8828 e- | |
| Dynamic range: 56.9 dB | |
| Signal-to-noise ratio: 39.5 dB | |
| Quantum efficiency: 38.7 % @ 465 nm, 42.3 % @ 536 nm, 45.2 % @ 631 nm | |
| Image formats, interface frame rate max.: Full Frame, 2592 x 2048 px, max. 73 fps Binning 2×2, 1296 x 1024 px, max. 73 fps Binning 2×1, 1296 x 2048 px, max. 73 fps Binning 1×2, 2592 x 1024 px, max. 73 fps | |
| Image formats, aquisition frame rate max. (Burst Mode): Full Frame, 2592 x 2048 px, max. 73 fps | |
| Pixel formats: BayerRG8, BayerRG10, Mono8, Mono10, RGB8, BGR8, etc. | |
| Analog controls: Gain (0 … 12 dB), Offset (0 … 63 LSB 10 Bit) | |
| Color models: Mono, Raw, BayerRGB | |
| Basic Functions: Exposure, Gain / Color Gain, Trigger / Exposure Active (Flash), Binning 2×2, Partial Scan, Offset, Free Running Mode (Live Image) | |
| Auto Functions: Exposure Auto, Gain Auto, White Balance Auto, Color Transformation Auto | |
| Image Pre-processing: Image Flipping (X/Y), Color Processing (RGB, BGR, Mono), Color Enhancement (with optimized ColorTransformationMatrix), LUT / Gamma | |
| Acquisition / Interface: Burst Mode, Adjustable Framerate, Device Link Throughput Limit, Internal Image Buffer | |
| Synchronization: free running, trigger | |
| Trigger sources: Hardware, Software | |
| Trigger delay: 0 … 2 sec, tracking and buffering of up to 256 trigger signals | |
| Process Synchronization: Events, Timer, Trigger Delay, Debouncer, Counter, Sequencer, Trigger via Action CMD (GigE), Additional Output Modes (e.g. Trigger Ready), Chunk data inside transferred image, Encoder support via Counter End trigger source | |
| Additional Functions: User Set, Integrated temperature sensor, Readable additional information (e.g. sensor information), Save Custom Data | |
| Internal image buffer: 471 MB (31 images in Trigger Mode, 1 image in Free Running Mode) | |
| Data interface: USB 3.0, Transfer Rate 5000 Mbits/sec, Connector: USB 3.0 Micro B | |
| Process interface: M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) | |
| Power supply: via USB 3.0 interface | |
| Lens mount: C-mount | |
| Dimensions: Width 29 mm, Height 29 mm, Depth 38 mm | |
| Weight: approx. 90 g | |
| Material: zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 | |
| Power consumption: approx. 3.9 W @ 73 fps | |
| Operating voltage: 5 VDC (via USB3.0 interface) | |
| Flash memory size: 128 kB | |
| Operating temperature: 0 … +65 °C @ T = measurement point | |
| Humidity: 10 … 90 % (non-condensing) | |
| Protection class: IP 40 | |
| Lines: 1 input line, 1 output line, 2 general purpose lines | |
| Conformity: CE, RoHS, K є (R-R-BkR-VCXU-53M), EAC |
