| connection types | cable 4 pin, 2 m |
| distance to focus | parallel beam |
| nominal range Sn | 10 m |
| reverse polarity protection | yes |
| type | rectangular |
| front (optics) | PMMA |
| height / length | 27 mm |
| manufacter SKU | OSDK 10D9005 |
| emitter / receiver | emitter |
| wave length | 650 nm |
| current consumption max. (no load) | 30 mA |
| width / diameter | 10,4 mm |
| current consumption typ. | 25 mA |
| laser class | 1 |
| voltage supply range +Vs | 11 … 30 VDC |
| actual range Sb | 8 m |
| type | through beam laser sensor |
| operating temperature | -10 … +50 °C |
| depth | 16,3 mm |
| protection class | IP 65 |
| light source | pulsed red laser diode |
| housing material | plastic (ASA) |
