| short circuit protection | yes |
| sync. input | yes |
| power on indication | LED green |
| front (optics) | glass |
| connector base (main connector) | DIN 45322, 6 pin |
| operating temperature | 0 … +50 °C |
| measuring distance Sd | 0 … 120 mm |
| connector base (interface) | DIN 45326, 8 pin |
| interface | serial for ScaDiag software |
| laser class | 2 |
| object speed | < 5 m/sec |
| protection class | IP 54 |
| output pulse length | 0,3 … 100 ms selectable |
| light source | pulsed red laser diode |
| direct gap detection | yes |
| counting rate | < 3000000 copies/h |
| optimum operating distance | 100 mm |
| current consumption max. (no load) | 230 mA |
| reverse polarity protection | yes |
| sensitivity adjustment | 4 preset levels or level set by customer |
| measuring point | visible red laser line 8 mm |
| object cycle distance | > 1 mm |
| width / diameter | 30 mm |
| manufacter SKU | FLDM 170G1030/S42 |
| voltage supply range +Vs | 10 … 30 VDC |
| type | rectangular |
| housing material | die-cast zinc |
| edge indicator | LED yellow |
| sensitivity | single sheet/edge thickness 0,15 mm |
| wave length | 670 nm |
| output circuit | push-pull |
| false pulse suppression | 4 program options |
Buy Baumer FLDM 170G1030/S42 with the best possible price and delivery terms on eltra-trade.com
Eltra Trade s.r.o. offers factory automation products. You can find a huge online catalog of automation equipment on our website. We provide super fast delivery to any country. Get the exclusive offer, contact us now! We strive to deliver your order on time, following our obligations. We are constantly developing to satisfy all your needs in electrical equipment supply.
