| beam diameter | 8 mm |
| linearity error | ± 1,5 … ± 4 mm |
| connection types | cable 4 pin, 2 m |
| soiled lens indicator | LED red |
| wave length | 660 nm |
| output current | |
| resolution | 0,1 … 1 mm |
| measuring distance Sd | 50 … 400 mm |
| power on indication | LED green |
| beam type | point |
| front (optics) | PMMA |
| output signal | 0 … 10 VDC |
| current consumption max. (no load) | 80 mA |
| alarm output | push-pull |
| adjustment | IO-Link |
| housing material | plastic (ASA, MABS) |
| short circuit protection | yes |
| operating temperature | 0 … +50 °C |
| type | rectangular |
| protection class | IP 67 |
| output circuit | analog |
| width / diameter | 14,8 mm |
| voltage supply range +Vs | 14 … 26 VDC |
| light source | pulsed point source LED |
| temperature drift | |
| load resistance (analog U) | > 100 kOhm |
| depth | 31 mm |
| manufacter SKU | FADK 14U4470/IO |
| Teach-in range min. | > 20 mm |
| height / length | 43 mm |
| response time / release time | |
| reverse polarity protection | yes, Vs to GND |
Buy Baumer FADK 14U4470/IO with the best possible price and delivery terms on eltra-trade.com
