The AMG 81 Baumer is an absolute encoder used for precise position measurement. It is equipped with a solid shaft with a diameter of 11 mm and a EURO B10 flange. This encoder supports multiple interfaces such as SSI, Profibus and CANopen, making it versatile for various applications.
Datasheet:
- Supply voltage: 9…30 VDC
- No-load consumption: ≤100 mA (SSI interface), ≤250 mA (bus interface)
- Initialization time: ≤200ms after power on
- Interfaces: SSI, Profibus-DPV0, CANopen
- Number of steps per revolution: 8192 / 13 bits
- Number of revolutions: 4096 / 12 bits, 65536 / 16 bits
- Additional outputs: quadrature TTL (RS422), quadrature HTL
- Measurement method: optical
- Working speed: ≤3500 rpm
- Operating torque: ≤10 Ncm
- Material: body — aluminum alloy, shaft — stainless steel
- Operating temperature: -20…+85 °C
- Protection: IP 55
- Weight: about 1.7 kg (depending on the version)
Product Variants:
AMG 81 C 13 H2048
AMG 81 C 13 T2048
AMG 81 C 13 Z0
AMG 81 C 25 H2048
AMG 81 C 25 T2048
AMG 81 C 25 Z0
AMG 81 C 29 H2048
AMG 81 C 29 T2048
AMG 81 C 29 Z0
AMG 81 P 13 H2048
AMG 81 P 13 T2048
AMG 81 P 13 Z0
AMG 81 P 25 H2048
AMG 81 P 25 T2048
AMG 81 P 25 Z0
AMG 81 P 29 H2048
AMG 81 P 29 T2048
AMG 81 P 29 Z0
AMG 81 S 13 H2048
AMG 81 S 13 T2048
AMG 81 S 13 Z0
AMG 81 S 25 H2048
AMG 81 S 25 T2048
AMG 81 S 25 Z0
AMG 81 S 29 H2048
AMG 81 S 29 T2048
AMG 81 S 29 Z0
AMG81 S13 H 2048
AMG81 S24 T 2048
AMG81 S25 H 2048
AMG81 S25 T 2048
AMG81 S25 Z0
