The FE4P30Q-U/35Q-U is a cost-effective electric forklift with combination of the traditional Internai Combustion forklift and lithium-iron powered electric forklift, it has the characteristics of large driving space and comfortable operation. The standard configuration is lithium iron phosphate (LFP) battery with efficient fast charging. Optional different battery capacities: the standard configuration is 80V200Ah, optional 80V300Ah and 400Ah. Standard full AC control System and optional fleet management System. Standard REMA/Anderson connection for charging, optional automotive type intelligent plug-in high frequency charging technology.The truck adopt similar design of the Internai Combustion forklift with spacious operation space and comfort. The mast System, front and rear axles as well as the the durability of châssis is similar to traditional Internai Combustion forklift. The truck combined the durability of Internai Combustion forklift with layout advantage of Li-iron electric forklift, so that the truck’s weight is light and and gravity center is optimized, therefore the overall energy consumption is effectively improved.
Технические характеристики
CharacteristicsMotor typebattery-poweredOperatorride-onOther characteristics4-wheelCarrying capacity
3,000 kg, 3,500 kg (6,613.9 lb)
Lifting height
3 m (910)
Overall width
1,226 mm (48.3 in)
Overall length
3,773 mm, 3,818 mm (148.5 in)
Load center distance
500 mm (19.7 in)
Weight without load
4,070 kg, 4,480 kg (8,972.8 lb)
Axle loading with maximum load front
6,390 kg, 7,140 kg (14,087.5 lb)
Axle loading with maximum load rear
680 kg, 840 kg (1,499.1 lb)
Axle loading without load front
1,750 kg, 1,960 kg (3,858.1 lb)
Axle loading without load rear
2,320 kg, 2,520 kg (5,114.7 lb)
Track width front
1,004 mm (39.5 in)
Track width rear
982 mm (38.7 in)
Height of mast when lowered
2,070 mm, 2,185 mm (81.5 in)
Free lift
140 mm, 145 mm (5.5 in)
Overall height with mast raised
2,150 mm (84.6 in)
Height to top of overhead guard
2,150 mm (84.6 in)
Seat height
1,130 mm (44.5 in)
Tow couplig height
580 mm (22.8 in)
Length to fork face
2,703 mm, 2,748 mm (106.4 in)
Fork carriage width
1,100 mm (43.3 in)
Ground clearance under mast with load
135 mm (5.3 in)
Ground clearance at center of wheelbase with load
150 mm (5.9 in)
Turning circle radius
2,400 mm, 2,440 mm (94.5 in)
Travel speed
11 km/h, 12 km/h, 13 km/h (6.8 mph)
Lifting speed
0.3 m/s (1 ft/s)
Lowering speed
0.6 m/s (2 ft/s)
Rated drawbar pull
2,500 N, 2,800 N, 3,500 N, 3,800 N
Gradeability
13 %, 15 %
Rated output
11 kW (15 hp)
Maximum operating pressure
17.5 MPa
Oil flow
36 l/min (9.5 us gal/min)
Noise level
74 dB, 75 dB
