Modular design: easy switch between different configurations due to special features and fitting devices Silicon-free Buttress thread for perfect fit of the union nut Integrated bracket for fix point mounting Integrated fixations for the modular adapter set: one-piece injected valve body Cushion O-ring for PTFE-seat Double sealed shaft Locking handle with integrated PLS (Praher Labelling System) Version with plastic screws available on request Seal materials — EPDM, FPM Ball seating joint — PTFE Connections — flange, PE fusion socket, PE fusion spigot, solvent socket, solvent spigot, threaded socket Approvals — KIWA NSF/ANSI/CAN 61, ACS
Технические характеристики
CharacteristicsTypeballOperationmanualMediafor potable waterBodyflange, threaded, modular, EPDM, PVC, IP65Number of channels2-wayOther characteristicsANSIDN
Max.: 80 mm (3.15 in)
Min.: 10 mm (0.394 in)
Pressure
16 bar (232.1 psi)
Temperature
Max.: 50 °C (122 °F)
Min.: -10 °C (14 °F)
Flow rate
Max.: 7,600 l/min (2,007.71 us gal/min)
Min.: 6 l/min (1.59 us gal/min)
