| Platform | Avanti |
| Maximum Speed | 10,200 rpm |
| Maximum g-Force | 11420 x g |
| Acceleration | 10 acceleration rates, including maximum torque |
| Deceleration | 11 deceleration rates, including maximum torque and no braking |
| Timed Run | 1 minute-99 hours, 59 minutes or Continuous Hold |
| Max Capacity Volume Range | — 3 L |
| Refrigeration System | Yes |
| Temperature Range(s) | From -10°C to +40°C in 1° increments |
| Pollution Degree | 2 |
| Installation Category | II |
| Material(s) | Painted Steel, Uncoated Plastic, Painted Aluminum, Plastic |
| Weight | 120 kg(264.6 lb) |
| Width | 75.6 cm(29.8 in) |
| Depth | 70.3 cm(27.7 in) |
| Height | 36.8 cm(14.5 in) |
| Clearances | 7.6 cm: side & rear |
| Humidity Restrictions | 80% (non-condensing) |
| Power Requirements | 120 VAC, 12A, 60 Hz |
