AUTOMATIC STRAPPING MACHINE TP 201 WITH SIDE SEAL — (ARCH CAN BE REALIZED ON REQUEST) Lateral automatic strapping tool for bulky packages . Standard arch mm. 600×850. Very reliable. The fully automatic strapping machine mod. TP 201 with side sealing is particularly suitable for strapping furniture, household appliances, palletised loads and high packages. It can be inserted in lines where the available space or the limited height of the conveyor do not allow the use of a standard strapping machine. The strap is automatically launched, tensioned, welded and cut, speeding up the strapping operations. The strapping machine, suitably modified, can be easily inserted into automatic packaging lines and can also work without an operator. The BASE strapping machine has the maximum useful dimension of mm. 600×850. On request it is possible to have the arch with useful dimensions mm. 600×1200 mm. (and up to a maximum of mm. 600×1800) Available in 4 versions: -TR 201 BS: semi-automatic standard model, side button operation — arc mm. 600×850 -TR 201 BSAG: semi-automatic standard model, side button operation — arc mm. 600×1200 -TR 201 BC: model equipped with front dual control and protective casing. Suitable for those who already own a semiautomatic line and want to add the strapping machine — arc mm. 600×1200 -TR 201 BCRL: model complete with front dual control, structure on wheels, idle roller conveyor of 1500 mm in input and 1500 mm in output with rollers diameter 30 mm and pitch 40 mm — arch on request
Технические характеристики
CharacteristicsTypeautomaticProduct applicationspallet, for production lines, for packaging, pallet, for logistics, for pallets, for industrial applications, PLCType of strappolypropylenePower supply380V three-phaseSectorfor the packaging industry, for logisticsOther characteristicslateralOverall height
1,730 mm (68.1 in)
Overall width
1,400 mm (55.1 in)
Depth
590 mm (23 in)
Package width
600 mm (24 in)
Package height
850 mm (33 in)
Strap width
12 mm (0.5 in)
Strip thickness
0.6 mm, 0.65 mm (0.02 in)
Puissance
0.85 kW (1.16 hp)
Clamping tension
80 kg (176.37 lb)
Weight
Min.: 200 kg (440.92 lb)
Max.: 200 kg (440.92 lb)
200 kg (440.92 lb)
