Non-contact residual solder removal From S to M and L to XL. *PCB format: length times width (each approx. max. limit): S = 300 x 250 mm, M = 390 x 285 (+x) mm, L = 535 x 300 mm, XL = 625 x 625 mm. High-quality 400 W hot gas/vacuum cartridge in suction head Spacious solder collecting tank Process gas cleaning Integration possible in HR 550 or HR 550 XL Process control via HRSoft 2 and clearly arranged operating elements The Technology of Ersa Rework-Systeme sustainably secures the added value of electronics: gentle heating technology sensor guided soldering processes contactless residual solder removal precise component placement complete process documentation clear user guidance >> Learn more about Ersa Rework Technology Dimensions (W x D x H) in mm: 300 x 210 x 420 mm Dimensions: required table space approx. 600 x 500 mm Weight in kg: 18,5 Antistatic Design (y/n): yes Power Rating in W: 400 Nominal voltage in V AC: 230 Upper heating: hot gas Compressed air connection: 60 l/min at 6 bar, oil free, quick coupling ¼ inch Component size in mm: all common SMD pad formats Operation: set elements and HRSoft 2 Test symbol: CE
Технические характеристики
CharacteristicsOperational modeautomaticApplicationsfor PCB
