Andor Technology Neo 5.5 CL3-F sCMOS *NEW* Microscope Camera

Description

Andors Neo 5.5 sCMOS camera is designed exclusively to drive highest possible sensitivity from this exciting and innovative new technology development. Neo 5.5 sets radical new benchmarks in its unique ability to simultaneously deliver highest specifications in sensitivity, resolution, speed, dynamic range and field-of-view: true scientific imaging, without compromise. Choice of Rolling and Global (Snapshot) exposure mechanisms ensure maximum application flexibility, the latter providing a freeze frame capture capability that emulates that of an interline CCD.

Specifications:

Sensor Type: Front Illuminated Scientific CMOS
Active Pixels: 2560 x 2160 (5.5 Megapixel)
Sensor Size: 16.6 x 14.0 mm (21.8 mm diagonal)
Pixel Size: 6.5 m
Pixel Readout Rate (MHz): 560 (280 MHz x 2 sensor halves). 200 (100 MHz x 2 sensor halves)
Read Noise (e-):
Rolling Shutter: 200 MHz 1.0 [1.5] , 560 MHz 1.3 [1.7]
Global Shutter: 200 MHz 2.3 [2.6], 560 MHz 2.5 [2.8]
Minimum Temperature Air Cooled 4: -30C
Minimum Temperature Coolant: -40C
Dark current, e- /pixel/sec 5:
-30C: 0.015
-40C: 0.007
Data Range: 12-bit and 16-bit
Peak Quantum Efficiency: 60 %
Readout Modes: Rolling Shutter and Global (Snapshot) Shutter
System Window Type: UV-grade fused silica, Broadband VS-NIR, unwedged
Lens Mount: F-mount
Internal Memory Buffer Size: 4 GB
Maximum Burst Frame Rates:
2560 x 2160 (full frame): 100 fps Rolling Shutter, 49 fps Global (Snapshot) Shutter
128 x 128 ROI: 1,639 fps Rolling Shutter, 716 fps Global (Snapshot) Shutter
Pixel Well Depth (e- ): 30,000
Maximum Dynamic Range: 30,000:1
Linearity (%, maximum) 6: Better than 99%
MTF (Nyquist @ 555 nm): 45%
Photon Response Non-Uniformity (PRNU):
Half-light range: &lt, 0.01%
Low light range: &lt,0.1%
Pixel Binning: Hardware Binning: 2 x 2, 3 x 3, 4 x 4, 8 x 8
Pre-defined Region of Interest: 2560 x 2160, 2048 x 2048, 1920 x 1080, 512 x 512, 128 x 128
Gain Register Pixel Well Depth76: 800,000 e-
User defined ROI Granularity: 1 pixel *
I/O: External Trigger, Fire, Fire n, Fire All, Fire Any, Arm
Hardware Timestamp Accuracy: 25 ns
Anti-blooming Factor: x 10,000
