Product Information
Metal travel distance is 3.000” for all blocks, and FBH diameter ranges from #1 (1/64) to #8 (8/64). In accordance with E428. Includes our NIST traceable dimensional certification report, ultrasonic inspection report and response plot from Tactic Inc, and the certified material test report. Note that we use a 5.0 MHz quartz transducer for block characterization as required by ASTM E127, Section 11.
- Dimensions: FBH diameters are 1/64, 2/64, 3/64, 4/64, 5/64, 6/64, 7/64, and 8/64. Block diameter is 2.0.
- Optional Hardwood Case recommended
