Description
KTAxpress Module
KTA xpress is a chromatography system designed for automated, multistep protein purification of both single and multiple samples.
- Unattended purification: Built-in purification knowledge combines software, hardware, and prepacked columns to eliminate time-consuming manual tasks.
- Highest possible purity: Optimized protocols with up to four steps will deliver tagged proteins of near 100% purity. Built-in cleaning procedures between MAb samples to minimize carry over
- High productivity: Each module can purify up to four proteins. The modular design offers adaptability to meet increased throughput needs.
- Yield : The system is capable of purifying target proteins in yields varying from 1 to 50+ mg.
- Akta Express has a Small footprint: A compact design allows the system to occupy minimal space on the bench or in the cold room.
KTAxpress Module
- Complete Packsize: 1 Piece
- Application: Unattended multistep purification of tagged proteins and antibodies
- Flow Rate: 0.1-65 ml/min
- Operating Pressure Max.: 3 MPa (435 psi)
- Tubing i.d. [Flow Path]: 1 mm
- Single Wavelength Detection: Mercury lamp and 254 and 280 nm filters included. Optional filters for 313, 365, 405, 436 and 546 nm.
- Multiple Wavelength Detection: No
- Flow Cell Path Length: 2 mm
- Multiple Sample Injection: Yes, up to 4 samples
- Autosampler Injection: No
- Automatic Buffer Preparation: No
- Buffer Selection: 10 buffer inlets
- Multi-Step Purification: Yes, up to 4 steps
- Relative Humidity: 20%-95% (non condensing)
- pH Stability Long Term: 2-12
- pH Stability Short Term: 1-14
- Viscosity: max 5 cP
- Width: 250 mm
- Height: 660 nm
- Depth: 600 mm
- Weight: 30 kg
- Voltage: 100-120/220-240 VAC
- Power Consumption: 120 VA
- Protection Class: IP 20
- Pump Type: Piston pump, metering type
