Product Description Space-saving design with lid opening upward. Agar sterilization mode for sterilizing agar and then automatically maintaining it at liquid temperature. Dual-sensing lid interlock prevents lid opening when chamber is pressurized or when temperature exceeds 97C. Agar melting mode for melting agar and maintaining it at liquid temperature, or for a hot, faster start-up. One-touch lever to easily open and close chamber lid. In-process display shows the status and the progress of sterilization cycle. Door-closure sensor provides a prompt and the cycle will not start unless the door is closed properly. HVE-50 size: 50 liters, 11.8 D, 28.0H. Technical Specifications TEMPERATURE Operating Range 105C to 135C Display Range 5C to 137C Warming Range 45C to 60C GAUGE PRESSURE Operating Range (gauge) 3 to 30 psi (0.021 to 0.206MPa) Maximum Allowable 38 psi ( 0.26MPa) TIMER Sterilization 1 to 250 minutes DIMENSIONS Overall (W x D x H) 20.1 x 20.8 x 40.9 (51 cm x 53 cm x 104 cm) Chamber (Diameter x Height) 50 liters 11.8 x 28 (30 cm x 71 cm) SAFETY DEVICES Dual-sensing lid interlock, over-pressure power cutoff, over-temperature power cutoff, low-water power cutoff, mechanical pressure relief valve, lid-closure detector, over-current detector and circuit breaker PROGRAMS 1. For agar/liquids. Also for melting agar, or for faster start-up Heating ->, Sterilization ->, Auto steam exhaust or ambient cooling (programmable) ->, Warming ->, Completion 2. For liquids/solids Heating ->, Sterilization ->, Auto steam exhaust or ambient cooling (programmable) ->, Completion 3. For solids Heating ->, Sterilization ->, Auto exhaust (fast) ->, Completion ACCESSORIES Stainless steel Mesh wire baskets, buckets (pails), and round test tube racks Factory or field installed Data logger POWER Source 120V, 50/60 Hz, single phase (220V available on request) Consumption 2000 watts (2000 VA) SHIPPING WEIGHT 180 lb (82 kg) WARRANTY: Autoclaves are protected by a 12-month warranty.
Технические характеристики
Technical Specifications
| TEMPERATURE | |
| Operating Range | 105ºC to 135ºC |
| Display Range | 5ºC to 137ºC |
| Warming Range | 45ºC to 60ºC |
| GAUGE PRESSURE | |
| Operating Range (gauge) | 3 to 30 psi (0.021 to 0.206MPa) |
| Maximum Allowable | 38 psi ( 0.26MPa) |
| TIMER | |
| Sterilization | 1 to 250 minutes |
| DIMENSIONS | |
| Overall (W x D x H) | 20.1′ x 20.8′ x 40.9′ (51 cm x 53 cm x 104 cm) |
| Chamber (Diameter x Height) | 50 liters 11.8′ x 28′ (30 cm x 71 cm) |
| SAFETY DEVICES | Dual-sensing lid interlock, over-pressure power cutoff, over-temperature power cutoff, low-water power cutoff, mechanical pressure relief valve, lid-closure detector, over-current detector and circuit breaker |
| PROGRAMS | |
| 1. For agar/liquids. Also for melting agar, or for faster start-up | Heating ->, Sterilization ->, Auto steam exhaust or ambient cooling (programmable) ->, Warming ->, Completion |
| 2. For liquids/solids | Heating ->, Sterilization ->, Auto steam exhaust or ambient cooling (programmable) ->, Completion |
| 3. For solids | Heating ->, Sterilization ->, Auto exhaust (fast) ->, Completion |
| ACCESSORIES | |
| Stainless steel | Mesh wire baskets, buckets (pails), and round test tube racks |
| Factory or field installed | Data logger |
| POWER | |
| Source | 120V, 50/60 Hz, single phase (220V available on request) |
| Consumption | 2000 watts (2000 VA) |
| SHIPPING WEIGHT | 180 lb (82 kg) |
WARRANTY: Autoclaves are protected by a 12-month warranty.
