The XT1 Series, engineered by Air Work, is a valve filter regulator and lubricator that makes use of air as its media. This device operates in an utmost pressure of 15 bar and a temperature of -10 / +50°C. In addition, it has wall clamping screws of 1=M4X14 2=M5X18 3=M6X20 and a bowl capacity of 1=22 cm3 2=46 cm3 3=89.5c m3.
Технические характеристики
CharacteristicsDesigned forair, compressed airFiltration elementcartridgeOther characteristicsmodularFlow
Min.: 1,000 l/min (264.172 us gal/min)
Max.: 4,250 l/min (1,122.731 us gal/min)
Operating pressure
Min.: 0 bar (0 psi)
Max.: 15 bar (217.557 psi)
Filtration size
Min.: 5 µm
Max.: 50 µm
