Description
Specifications:
- GLP features: Early maintenance feedback (EMF), electronic records of maintenance and errors
- Communications Controller: area network (CAN). RS232C, APG-remote standard, optional four external contact closures and BCD vial number output
- Safety features: Leak detection and safe leak handling, low voltages in maintenance areas, error detection and display
- Injection range:
- 1 – 100 μl in 0.1 μl increments
- Up to 1500 μl with multiple draw (hardware modification required)
- Precision:
- Typically <, 0.5 % RSD of peak areas from 5 – 100 μl,
- Typically <, 1 % RSD from 1 – 5 μl
- Sample viscosity range: 0.2 – 5 cp
- Sample capacity:
- 2 × well-plates (MTP) + 10 × 2 ml vials
- 100x2ml in one tray
- 40 x 2 ml in half tray
- Injection cycle time:
- Typically <, 30 s using following standard conditions:
- Default draw speed: 200 μl/min
- Default eject speed: 200 μl/min
- Injection volume: 5 μl
- Carry-over Typically:
- <, 0.01 % using the following conditions:
- Column: 125 x 4 mm Hypersil ODS, 5 μm
- Mobile phase: Water/Acetonitrile = 80/20
- Flow rate: 1 ml/min
- Injection volume: 1 μl caffeine (1 mg/ml), 5 μl water to test carryover
- Outside wash of needle before injection: 20 sec with water using flush port
