Description
Agilent Seahorse XFe96 Analyzers measure the oxygen consumption rate (OCR) and extracellular acidification rate (ECAR) of live cells in a 96-well plate format.
OCR and ECAR rates are key indicators of mitochondrial respiration and glycolysis as well as ATP production rate. Together these measurements provide a systems-level view of cellular metabolic function in cultured cells and ex vivo samples.
Specifications:
Amperage: 9 A
Analyzer Application: Phenotyping Screening
Assay Running Volume: 150 275 L/well
Assay Wells: 92
Communication: TCP/IP, USB, wireless
Controller Description: Combination of Windows 10 computer and touchscreen display with full assay design, control, and analysis capability
Controller Touchscreen: Yes
Controller Type: Cable-connected
Depth: 43 cm
Height: 61 cm
Injection Ports per Well: 4 per well
Memory: 16 GB
Microchamber Volume: 2.8 L
Operating Environment Relative Humidity: 20 80 %
Operating Environment Temperature: 4 30 C
Operating Voltage: 100 240 VAC
Sample Requirements: 5000 500000 cells/well
Sample Temperature: 16 42 C
Software Included: Wave Controller, Windows 10 Enterprise, Wave Desktop unlimited use license
Volume per Port Injection: 25 L
Weight: 23 kg
Width: 41 cm
