Description
The Agilent 1290 Infinity Flexible Cube is an auxiliary module for the 1290 Infinity Autosampler with a built-in pump to facilitate enhanced flushing capabilities and to reduce carry-over. With access to three solvents, critical sections of flow path can be flushed at high flow rates. Automated back-flushing of the injection needle-seat achieves the absolute lowest sample carryover for LC and LC/MS applications. In addition, the Flexible Cube hosts up to two Agilent Quick-Change valves. For utmost flexibility, choose among Agilents broad portfolio of available valve heads suitable up to 1200 bar. The valves can be controlled independently for any demanding valve-switching application.
Specifications
- Injection range
- 1 20 &mu,L
- .1 40 &mu,L
- .1 100 &mu,L
- in 0.1 &mu,L increments
- Precision: Precision of G4226A sampler will not be influenced
- Accuracy: Accuracy of G4226A sampler will not be influenced
- Sampler pressure range: Up to 1200 bar
- Pressure range of flush pump: Up to 50 bar
- Flow rate of flush pump: Up to 4 mL/min
- Number of solvents: Up to 3 solvents
- Sample viscosity range: 0.2 5 cp
- Carry over: Typically <,0.001% (10 ppm)
