Description
Specification:
- Detection type: Double-beam photometer
- Light source: Deuterium lamp
- Wavelength range: 190600 nm
- Short term noise (ASTM): ±,0.7510-5 AU at 254 nm
- Drift: 3 10 -4 AU/hr at 254 nm
- Linearity: 2 AU (5%) upper limit
- Wavelength accuracy:
- Band width: 5 nm typical
- Flow cells:
- Standard: 14-&mu,l volume, 10-mm cell path length and 40 bar (588 psi) pressure maximum
- High pressure: 14-&mu,l volume, 10-mm cell path length and 400 bar (5880 psi) pressure maximum
- Micro: 1-&mu,l volume, 5-mm cell path length and 40 bar (588 psi) pressure maximum
- Semimicro: 5-&mu,l volume, 6-mm cell path length and 40 bar (588 psi) pressure maximum
- Control and data evaluation: Agilent ChemStation for LC
- Analog outputs: Recorder/integrator: 100 mV or 1 V, output range 0.001 2 AU, one output
- Communications: Controller-area network (CAN), GPIB, RS-232C, APG Remote: ready, start, stop and shut-down signals, LAN optional
- Safety and maintenance: Extensive diagnostics, error detection and display (through control module and Agilent ChemStation), leak detection, safe leak handling, leak output signal for shutdown of pumping system. Low voltages in major maintenance areas.
- GLP features: Early maintenance feedback (EMF) for continuous tracking of instrument usage in terms of lamp burn time with user-settable limits and feedback messages. Electronic records of maintenance and errors. Verification of wavelength accuracy with built-in holmium oxide filter
- Housing: All materials recyclable.
