Description
The AEMC Model JM813 AC Current Probe has Excellent transformation and low phase shift, plus a broad frequency response, permit accurate measurements of current and power. The high quality magnetic cores and uniform windings provide for accurate measurements up to 3600AAC. The ‘squared’ jaw permits multiple conductor or bus bar positioning. The Model JM813 provides excellent True RMS capabilities and reliable signal reproduction.
The Model JM813 works as a traditional current transformer providing current outputs (mA) over a broad range of transformation ratios. The Model JM813 is designed for use on DMMs, power and harmonic meters, recorders or instruments with AC current ranges.
Applications include:
- Field testing
- Electrical utility
- HVAC
- Industrial maintenance
- Laboratory
- Plant maintenance
Технические характеристики
Features
- Nominal range: up to 3000AAC
- Measurement range: 1 to 3600A
- Transformation ratio 3000:3
- Operating temp: 14 to 122°F (-10 to 50°C)
- Output: 1mA/A
- Designed for use on DMMs, power and harmonic meters, recorders or instruments with AC current ranges
- Jaw opening 3.54′ (90mm)
