The Pump Set is suitable for corrosive, aqueous to slightly viscous media. Perfectly suited for the withdrawal or decanting of acids. • Media examples: Hydrochloric acid, battery acid, iron-III-chloride, phosphoric acid, chromic acid and citric acid etc. • Pump tube equipped with Lutz original hand wheel • Suitable for filling or decanting oils such as rapeseed oil and vegetable oil Features & Advantages • Optionally with electric or compressed air drive • No lubricants and therefore no contamination of the pumped medium by lubricants • Optimized Drum emptying • Universally resistant PTFE shaft bearing • Maintenance without special tools • Seal modules of the seal-less (DL) pump are exchangeable * The maximum flow rate is a value determined by means of a test bench and measured with water at a liquid temperature of approx. 20 °C . The measurement is taken at the pressure joint of the pump, without hose, nozzle or flow meter.The achievable flow rate in use is lower and depends on the individual application, the liquid properties and the configuration of the pump.The max. delivery head also depends on the pump design, motor and fluid.The viscosity values are determined with oil.
Технические характеристики
CharacteristicsFluidacidOperationwith electric motorPrimingsemi-submersibleTechnologyimpellerMobilitystationaryDomainindustrial, chemistry, for the petrochemical industry, for the automotive industry, for the printing industryApplicationstransfer, drum, drainMaterialpolypropyleneFluid specificationfor low-viscosity fluids, for corrosive fluidsVoltage230 VOther characteristicsradial, corrosion-proof, seal-less, with variable-speed controllerFlow
Min.: 0 l/min (0 us gal/min)
Max.: 50 l/min (13.2086 us gal/min)
Head
Min.: 0 m (000)
Max.: 19 m (6204)
Power
500 W (0.68 hp)
Fluid temperature
50 °C (122 °F)
Input diameter
41 mm (1.6 in)
