VEICHI provides OEM/ODM Service for TOP Customers. VEICHI V7E Series Servo Motor is used together with the newly upgraded SD700 servo drive. Excellent performance design enables our motors to be widely used in various industrial fields, such as machine tools, the packaging industry, industrial robots, and so on. Product Advantages： 1. Cost-effective 2. Better out 3. Lower temperature rise 4. Higher precision 5. Shorter length 6. Better protection Applications： Electronic manufacturing equipment, numerical control equipment, packaging machinery, printing machinery, textile machinery, plastic machinery and glass equipment, testing equipment, etc. Rated input voltage: 220V，380V Flange:40mm—180mm Encoder type: 23-bit muti-turn absolute value 17-bit single-turn absolute value 17-bit muti-turn absolute value More details: https://www.veichi.com/product/v7e-series-servo-motor.html
Технические характеристики
CharacteristicsAC/DCAC, DCTypeasynchronousVoltage 220 V, 380VProtection classIP67Configurationpermanent magnet, with brakeCooling mechanismair-cooledApplicationsindustrial, packaging machine, for machine tools, for robotics, for the pharmaceutical industry, with built-in encoder, food, for compressorsOther characteristicsperformance, CNC, low-voltage, motion control, direct-drive, EtherCAT, CANopen, closed-loopPower
Max.: 7.5 kW (10.197 hp)
Min.: 0.1 kW (0.136 hp)
Current
Max.: 17 A
Min.: 10.9 A
Torque
Max.: 47.75 Nm (35.2186 ft.lb)
Min.: 28.01 Nm (20.6591 ft.lb)
Rotational speed
2,000 rpm (12,566.37 rad.min-1)
Diameter
Max.: 180 mm (7.09 in)
Min.: 40 mm (1.57 in)
