Metric 42R-5N Series AC Right Angle Gearmotor Application Information • Capacitor is not included, order with motor if required. • Mounting is via 4 feet on the gearhead • Die cast terminal box with terminal block installed. IP-44. Optional Accessories Die cast terminal box kit for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 0984] Die cast metric terminal box kit with terminal block for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 1984] Capacitor, plastic box type, 7.5MFD 370V [Item 49401154] Die cast terminal box kit for our 42R-FX stock gearmotors [model 0985] — Use model 0986 instead Large die cast terminal box kit for 34R, 42R, 48R, 42R-FX, 33A, 42A stock motors and gearmotors [model 0986] STANDARD FEATURES • Metric mounting threads and metric drive shaft dimensions. • Totally enclosed IP-20 rating • Fan cooled for high output power • Class ‘B’ insulation system operated within Class ‘A’ limits to prolong winding and lubricant life • Aluminum center ring and endshields for high thermal efficiency and light weight • Unvented gearhousing. • Industrial lip type seals on motor and output shafts • Needle bearings throughout for increased radial load capacity and long life • Permanently lubricated gearing utilizing oil for long life • Bronze worm gear for high shock load capability • Hardened and ground worm gear for strength and long life
Технические характеристики
CharacteristicsMotor typeACTypewormShaft orientationright anglePower100 W…500 W, 50 W…100 WVoltage 230 VTorque10 — 20 Nm, 5 — 10 NmProduct applicationsindustrialOther characteristicscompact, efficiency, high load capacity
