Please Note you can specify and order your pressure gauge in our webshop https://store.ametekstc.com/pressure-gauges/test-gauges/ Model 1403 SOLFRUNT Test Gauges are panel mount pressure gauges used for testing and validation, with an ASME B40.100 Grade 3A accuracy (±0.25% FS). The Model 1403 has a chemical-resistant aluminum solid front, panel mount case with a blow out back design. This pressure gauge has a mirrored dial and knife-edged micro-adjustable pointer to reduce parallax readings. The 1403 is available in both 4½” and 6” gauge sizes, the larger size provides better dial readability. The gauge has a low back mount brass socket available in both a ¼” or ½” NPT connection, with a seamless phosphor bronze or beryllium cooper bourdon tube. Pressure ranges are from Vacuum to 5000 psi. The Model 1403 has a geared ARC-LOC movement to minimize friction and wear. These gauges are available with a NIST Calibration Certificate option. NIST Calibration Certificate Order Code: /C — NIST (National Institute of Standards and Technology) Certification of Calibration states that the pressure gauge was tested at multiple test points and is within its stated tolerance of accuracy. Gauge is shipped with a sticker on the side of the gauge noting the certification number and date, and NIST certificate. Oxygen Cleaning Order Code: CL — The wetted surfaces of the gauge are cleaned and tested to ASME B40.100 Level IV Cleanliness, capped and bagged to maintain cleanliness during shipment.
Технические характеристики
CharacteristicsPressure typeabsoluteDisplaydialMountingthreaded, panel-mount, back mountMaterialbrass, aluminumTechnologyBourdon tubeProtection levelchemical-resistantApplicationsfor vacuum, calibration, test, laboratoryOther characteristicsadjustable, with safety casePressure
Max.: 5,000 psi
Min.: 0 psi
Precision
0.25 %
Dial diameter
4.5 in, 6 in
