COLOR: Translucent with high adhesion TPU coated coppered steel spiral DIAMETER RANGE: 20mm e 40mm FEATURES Ester based Polyurethane duct reinforced with a TPU high adhesion coated copper colored steel spiral. Totally smooth inside to ensure optimization of flow properties. Constant wall thickness of 0,7 mm through all the diameter range Strong but light and flexible, it’s suitable to heavy duty applications where a very good abrasion resistance is required. In fact its capability of abrasion resistance is 20 mm3, 50% more than that of a conventional TPU hose Resistant to mineral oils, ageing, atmospherical agents, ozone and to most chemicals. Free of Halogen NEXT 07 is made by a special TPU that combines different properties which make the wall material permanent antistatic (109 Ohm/metre) and resistant to UV. Thanks to the excellent quality of compound used, the hose is more resistant to Hydrolysis than a conventional Ester-based TPU hose. It can be made conductive (102 Ohm/metre) by grounding the spiral. APPLICATION: Suction of granules, abrasive powders, pellets, sawdust, fumes and abrasive powders. Suitable to be used in plastic, woodworking, ceramic, dust extraction industries
Технические характеристики
CharacteristicsUsefor bulk materials, for powdersMaterialTPUApplicationssuction, heavy-duty, for the wood industry, for the plastics industryOther characteristicsUV-resistant, flexible, abrasion-resistant, chemical-resistant, copper-coated, lightweight, oil-resistant, with smooth inner surface, anti-static, translucent, spiral wire, rugged, reinforced, for abrasive productsInner diameter
Max.: 203.2 mm (8 in)
Min.: 50.8 mm (2 in)
Temperature
Max.: 90 °C (194 °F)
Min.: -40 °C (-40 °F)
Delivered length
15 m, 20 m, 30 m (4902)
