| 50Hz AC Input |
| Ten-turn Output Voltage and Current Controls |
| Chassis Slides |
| 115 Vac ±10% Single-Phase Input |
| Voltage and Programming Adjust |
| 115 Vac ±10% Single-Phase Input |
| 208 Vac ±10% Single-Phase Input |
| 230 Vac ±10% Single-Phase Input |
| Resistance Programming Interface (Includes Option 022) |
Additional Features:
- Voltage: 60V
- Current: 15A
- Power: 900W
- Over-voltage protection
- Analog programmable
- Remote sensing
- Auto-series, auto-parallel, and auto-tracking operation
- <,50us load transient recovery
- Ripple and noise (20 Hz to 20 MHz): CV: 200 uV RMS, 20 mV peak-to-peak, CC: 5 mA RMS
- Load regulation: 0.01% + 200 uV, 0.02% + 500 mA
- Line regulation: 0.01% + 200 uV, 0.02% + 500 mA
The Agilent HP 6274B is a high-performance constant voltage/constant current power supply with an output rating of 0-60 Volts. The Agilent HP 6274B employs a transistor series-regulator/triac-preregulator circuit to achieve high efficiency, excellent regulation, low ripple and noise, and moderate programming speeds in a compact full-rack width package.
Технические характеристики
| Manufacturer | Agilent, HP, Keysight |
|---|---|
| Condition | Used |
| Current | 15 A |
| Voltage | 60 V |
| Power | 900 W |
