| 50Hz AC Input |
| Ten-turn Output Voltage and Current Controls |
| Chassis Slides |
| 115 Vac ±10% Single-Phase Input |
| Voltage and Programming Adjust |
| 115 Vac ±10% Single-Phase Input |
| 208 Vac ±10% Single-Phase Input |
| 230 Vac ±10% Single-Phase Input |
| Resistance Programming Interface (Includes Option 022) |
Additional Features:
- Voltage: 20V
- Current: 20A
- Power: 400W
- High-Performance CV/CC Supply
- Excellent Regulation
- Low Ripple and Noise
- Moderate Programming Speeds in a Compact Full-Rack width Package
- Transistor Series-Regulator/Triac-Preregulator Circuit to achieve High Efficiency
- Built-in overvoltage protection
- Remote programming and sensing
- Auto-series, Auto-parallel and Auto-tracking operation
The Agilent 6264B employs a transistor series-regulator/triac-preregulator circuit to achieve high efficiency, excellent regulation, low ripple and noise, and moderate programming speeds in a compact full-rack width package. Separate coarse and fine voltage and current controls allow the voltage and current outputs to be varied from zero to the maximum rated value, crossover from constant voltage to constant current operation occurs automatically when the load current exceeds the value established by the current control settings.
Технические характеристики
| Manufacturer | Agilent, HP, Keysight |
|---|---|
| Condition | Used |
| Current | 20 A |
| Voltage | 20 V |
| Power | 400 W |
