HIGHLIGHTS: ✅Ultrasonic spindle independently developed by Conprofe adopted to reduce cutting force, thus realizing high-efficiency machining for hard-machining material ✅Supercritical CO2 internal cooling system and MQL system available for clean machining ✅Full closed loop control enabled by High Precision Linear Encoder ✅Excellent X/Y/Z axis repeatability accuracy and A/C axis repeatability accuracy ✅SIEMENS 840Dsl adopted to realize 5-axis simultaneous machining with RTCP Function APPLICATION: Ideally suited for high-precision and high-efficiency 5-axis simultaneous ultrasonic or traditional machining of geometrically complicated workpieces of hard-brittle materials (ceramics, sapphire, glass, etc.), carbon fiber reinforced plastics and metal materials
Технические характеристики
CharacteristicsNumber of axes5-axisSpindle orientationverticalMachined materialfor composites, for plastics, for glass, for ceramics, quartz, for hard and brittle materialsSpindle mountHSK-A 100Number of tool stations40 toolsApplicationsfor the automobile industry, cutting, drilling, for the aeronautical industry, for automatic tool changers, for medical applications, for aeronautics, for profiles, for aluminum profiles, for the plastics industry, for aluminum plates, for the steel industryOther characteristicshigh-speed, high-performance, high-productivity, high-precision, ultrasonicX travel
1,100 mm (43 in)
Y travel
1,100 mm (43 in)
Z travel
700 mm (28 in)
Rotational speed
12,000 rpm (75,398 rad.min-1)
Workpiece max height
1,100 mm (43 in)
Table rotation (C axis)
50 °
Work feed X-axis
30,000 mm/min (20 in/s)
Work feed Y-axis
30,000 mm/min (20 in/s)
Work feed Z-axis
30,000 mm/min (20 in/s)
Table load capacity
1,000 kg (2,205 lb)
Tool weight (max)
25 kg (55.1 lb)
Positioning accuracy
0.008 mm (0 in)
Repeatability
0.007 mm (0 in)
Weight
25,000 kg (55,115.57 lb)
Overall length
3,200 mm (126 in)
Overall width
4,200 mm (165.4 in)
Overall height
4,000 mm (157.5 in)
