4-axis machining center AIM 4420-7420verticalfor aluminumfor PVC

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

AIM 4420 is a 4-axis servo-controlled machining center that is designed to perform drilling, grooving, notching, taping, sawmilling, etc. on all kinds of aluminum & PVC profiles, light alloys in general and thin-walled steel profiles. Efficient and economic processing on the three sides of the profiles is possible with this fully automatic machining center. General Features: • It is designed to make operations on three surfaces of the profiles such as a hole, slot, corner relieve, saw cutting, tapping, flow drilling, etc. • CNC automation system providing motion control at 4-axis • Linear type of magazine unit for 11 standard tools and Ø180 mm of the saw blade • Flow drilling and tapping feature by means of encoder spindle (optional) • Automatic clamp recognition and clamp positioning are available • CNC controlled spray tool lubrication system • Pneumatically working 4 pcs of clamps for gripping the workpiece • 2 x pneumatic rests used for resetting the workpiece in the X direction • 21’’ color touch screen • Program import via USB flash memory stick • Technical support via remote connection capability • Standard ISO ‘G’ code programming language • Special sound insulation cabinet around the machining center • Lubrication cartridge system for X, Y and Z axis  Optimum operational safety guaranteed by the 3-zone field scanner system • Multi-language support • Solid steel construction of the body and dynamic performance gantry • The LED lighting in the cabinet • Working capacity 4020x350x200
