TTH034BVT-01C | 3.4- inch Touch Display | 180×640 | MCU | In-Cell Capacitive Touch The bar touch display has unique features: – Ratio of about 3.5, suitable for applications with long interface design – In-cell capacitive touch, which can provide the touch function without additional touchscreen – Customize the cover glass to match the appearance of your terminal. – This Liquid Crystal Display has a built-in JD9365DA controller. The material is RoHS-compliant. Diagonal (inch): 3.4″ Resolution (pixel): 180×640 Display Type: IPS Display Mode: Transmissive Optimal View: Full View Touch Screen: In-Cell Capacitive Touch Module Dimensions (mm) (W x H x D): 25.72×88.83×1.6 Active Area (mm) (W x H): 23.22×82.56 Luminance (cd/m2): 400 Interface: MCU Driver IC: AXS15230 Operational Temperature (°C): -20 ~ +70 Storage Temperature (°C): -30 ~ +80
Технические характеристики
CharacteristicsTypeTFT, IPS, capacitive touch screenFormat180 × 640Screen size3.4″Applicationsinstrumentation, control, HMIOther characteristicsMCU, portable, LED-backlitWidth
25.72 mm (1.0126 in)
Height
88.83 mm (3.4972 in)
