Product Details
| Primary brand | Phoenix Contact |
| Main function | Interface unit |
| Product series / family name | MINI ANALOG PRO |
| Functions | Output-loop-powered 2-way isolator for the electrical isolation of unipolar and bipolar analog signals |
| Connection type (electrical) | Terminals (Spring) |
| Connection type | Push-in spring-clamp connections |
| Net Width (mm) | 6.2mm |
| Mounting mode | DIN rail |
| Mounting mode | DIN rail |
| Analog inputs quantity | 1 |
| Analog inputs type | Current |
| Analog inputs | 1 x analog input (0-2mA to 0-40mA (16 ranges) / 0-50 mV to 0-30 V (58 ranges)) |
| Analog outputs quantity | 1 |
| Analog outputs type | Current |
| Analog outputs | 1 x analog output (4-20mA) |
| Analog output currents | 4-20mA |
| Manufacturer product status | Commercialized |
| Compliant with standard(s) | CEEx II 3 G Ex nA IIC T4 Gc XUL 508 ListedClass I Div. 2 Groups A B C D T6Class I Zone 2 Group IIC T6HL 1 — HL 2HL 1 — HL 2HL 1 — HL 2EN 61000-4-6EMC directiveEN 61000-6-4EN 61000-4-6IEC 61010-1Ex II 3 G Ex nA IIC T4 Gc XUL 508 ListedClass I Div. 2 Groups A B C D T6Class I Zone 2 Group IIC T6HL 1 — HL 2HL 1 — HL 2HL 1 — HL 2 |
| Location of origin | DE (Germany) |
| Net weight | 0.120kg |
| Product title | Output-loop-powered 2-way isolator for the electrical isolation of unipolar and bipolar analog signals — Phoenix Contact (MINI ANALOG PRO) |
