Технические характеристики
Product Details
| Primary brand | Phoenix Contact |
| Main function | Transducer |
| Product series / family name | MINI ANALOG PRO |
| Functions | Universal frequency and PWM signals transducer |
| Supply voltage (DC) | 9.6-30Vdc (12Vdc / 24Vdc nom.) |
| Connection type (electrical) | Terminals (Screw-clamp) |
| Connection type | Screw-clamp connections |
| Net Width (mm) | 6.2mm |
| Mounting mode | DIN rail |
| Mounting mode | DIN rail |
| Digital inputs quantity | 1 |
| Digital inputs type | Counter |
| Digital inputs | 1 x digital input (NPN/PNP pulses up to 200kHz / PWM 2-98%) |
| Analog outputs quantity | 1 |
| Analog outputs type | CurrentVoltage |
| Analog outputs | 1 x analog output (0-21mA / 0-10.5Vdc, freely adjustable) |
| Manufacturer product status | Commercialized |
| Compliant with standard(s) | CEEx II 3 G Ex nA IIC T4 Gc XUL 508 ListedClass I Div. 2 Groups A B C D T5Class I Zone 2 Group IIC T5DNV GL TAA000021EHL 1 — HL 2HL 1 — HL 2HL 1 — HL 2EN 61000-4-6EMC directiveEN 61000-6-4EN 61000-4-6IEC 61010-1Ex II 3 G Ex nA IIC T4 Gc XUL 508 ListedClass I Div. 2 Groups A B C D T5Class I Zone 2 Group IIC T5HL 1 — HL 2HL 1 — HL 2HL 1 — HL 2 |
| Location of origin | DE (Germany) |
| Net weight | 0.120kg |
| Product title | Universal frequency and PWM signals transducer — Phoenix Contact (MINI ANALOG PRO) |
