Additional Features:
- Function test up to 20A
- AC/DC/IR/GB/LC five instruments in one
- Programmable voltage output and limit value
- OSC OPEN/SHORT check
- Flashover detection
- Human protection circuit
- Multi-scan device support dynamic leakage current test
- Standard RS232 Interface
- Optional GPIB Interface
- Large LCD panel
- Front panel lockout function
- Support PC Software
- UL/TUV/CE
The 19032 is a 5-in-1 Safety Analyzer. It can perform 5 safety test functions for electronic products including AC/DC HiPot, insulation resistance, grounding resistance and dynamic leakage current. The dynamic leakage current scan device (A190305/ A190307) can be connected externally or built in to 19032. It is capable of measuring complex safety requirements, installs and operates easy, and is the best choice to increase test efficiency.
The Model 19032 has Twin-Port and OSC function to minimize the test time significantly, along with the large screen display and intelligent operation mode, 19032 is the most powerful single unit for auto safety testing.
Технические характеристики
| Manufacturer | Chroma |
|---|---|
| Condition | New |
