| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8536.10.00.40 |
| Maximum Voltage Rating | 16VDC |
| Maximum Current Rating (A) | 100 |
| Hold Current (A) | 5 |
| Trip Current (A) | 8.5 |
| Minimum Initial Resistance (Ohm) | 0.015 |
| Maximum Post Trip Resistance (Ohm) | 0.034 |
| Typical Power Dissipation (W) | 2.6 |
| Maximum Trip Time (s) | 2@25A |
| Termination Style | Radial |
| Terminal Pitch (mm) | 5.1(Typ) |
| Number of Terminals | 2 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Packaging | Bulk |
| Size (mm) | 10.4 X 3 X 14.3 |
| Wire Form | Straight |
| Lead Diameter (mm) | 0.81 |
| Product Length (mm) | 10.4(Max) |
| Product Depth (mm) | 3(Max) |
| Product Height (mm) | 14.3(Max) |
| Seated Plane Height (mm) | 14.3(Max) |
| Mounting | Through Hole |
| Approval Agency | cURus, TUV |
| California Prop 65 | Warning Information |
| Current — Hold (Ih) (Max) | 5A |
| Current — Max | 100A |
| Current — Trip (It) | 8.5A |
| ECCN | EAR99 |
| Height — Seated (Max) | 0.563″» (14.30mm) |
| HTSUS | 8533.40.8070 |
| Lead Spacing | 0.201″» (5.10mm) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mounting Type | Through Hole |
| Operating Temperature | -40В°C ~ 85В°C |
| Package | Bulk |
| Package / Case | Radial, Disc |
| Resistance — Initial (Ri) (Min) | 15 mOhms |
| Resistance — Post Trip (R1) (Max) | 34 mOhms |
| RoHS Status | ROHS3 Compliant |
| Series | POLY-FUSEВ®, 16R -> |
| Size / Dimension | 0.409″» L x 0.118″» W (10.40mm x 3.00mm) |
| Time to Trip | 2s |
| Type | Polymeric |
| Video File | Building Automation – Protect/Sense/ControlBasic |
| Voltage — Max | 16V |
| Brand | Littelfuse |
| Current Rating — Max | 100 A |
| Factory Pack Quantity | 500 |
| Hold Current | 5 A |
| Manufacturer | Littelfuse |
| Maximum Operating Temperature | +85 C |
| Maximum Voltage | 16 V |
| Minimum Operating Temperature | -40 C |
| Mounting Style | Through Hole |
| Pd — Power Dissipation | 2.6 W |
| Product Category | Resettable Fuses-PPTC |
| Product Type | Resettable Fuses-PPTC |
| Resistance | 34 mOhms |
| Subcategory | PPTC Resettable Fuses |
| Tradename | POLY-FUSE |
| Trip Current | 8.5 A |
| Количество | Цена/шт (руб.) |
| 1 | 257 руб. |
| 10 | 202 руб. |
| 50 | 150 руб. |
| 100 | 137 руб. |
| 500 | 115 руб. |
| 1000 | 102 руб. |
| 5000 | 94 руб. |
| 10000 | 90 руб. |
16R500GU (Самовосстанавливающиеся предохранители — PPTC)
214 ₽
Купить 16R500GU от 1 шт в Москве. Производитель LITTELFUSE.
В наличии на складе 4310 шт.
Доставка импортных компонентов Littelfuse по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.
Оплата физическими и юридическими лицами безналичным расчетом.
Цена может измениться после запроса у поставщика!
